Addressing the Manufacturing Industry's Challenges Head-on

Quality Die Sets and Crimping Applicators in
Clinton Township, MI

Our die sets and crimping applicators are the gold standard in the industry. Meticulous attention to detail, rigorous testing, and proven manufacturing processes result in tools that increase your operational efficiency, reduce machine downtime, and improve your output quality.

Beyond the tooling benefits, partnering with Diamond Die means that you are part of a business relationship built on trust and reliability. We aim to fulfill your tooling requirements and foster a partnership for continuous improvement and operational excellence.

Hi-Speed Crimp
Applicator

Experience our high-speed applicators, ideal for handling high-volume signal-level terminals. We offer versatile feed guide options, including left-to-right, right-to-left, and end-to-end. These applicators are expertly designed to be compatible with the most widely used presses in the wire termination industry.

LEARN MORE

Heavy Duty Dies
(Wire Terminating Equipment)

Diamond Die offers an array of impressive heavy-duty dies designed specifically for handling larger cables. These make an optimal choice for high-voltage and conventional battery cables used in electric vehicles. The heavy-duty die’s convenient single-piece shuttle design simplifies the loading and unloading process for larger terminals. It features a vital limit switch for operator safety. Furthermore, it could be outfitted with a pneumatically-driven feed guide system to accommodate various terminal feeding directions—from left to right, right to left, or end (back) fed.

LEARN MORE

Hydrofeed Terminating
Applicator

Our Hydrofeed (Medium Duty) applicators are versatile tools designed for mid-sized termination tasks. With an adjustable feed system, these applicators can handle single or multiple terminations—up to four at once, depending on the wire and terminal sizes. Their larger opening, unlike a High-Speed applicator, facilitates the termination of unique customer applications.

LEARN MORE

Our Route to Consistent Innovation

Unparalleled Benefits of Our Die Sets and Crimping Applicators

Diamond Die offers three specialized applicators that set a new industry standard. With a focus on performance and reliability, these applicators are built to accommodate various wire sizes and terminal types, serving many industries, from home appliances to the automotive industry.

Every Diamond Die applicator is meticulously engineered to meet the demands of intensive manufacturing processes. Our applicators provide remarkable consistency, ensuring each crimp meets the exact specifications you require, enhancing the overall quality of your production.

Contact Us

The Unique Benefits of Our Crimping Applicators

HI-SPEED CRIMP APPLICATOR

  • Diamond Hi-Speed crimping applicators can be adapted to fit virtually any type of press, such as AMP crimping presses, Benchmaster, Mecal, Kenco, Perkins, Artos, etc.
  • The Diamond terminating applicator is built to handle the demands of automatic cut, strip, and terminating machines such as Komax, Artos, Toyojamco, AMP crimper, Tyco crimp machine, etc.
  • Applicator designed for either Left-to-Right, Right-to-Left, or End-to-End Feed terminals (Feeds on Upstroke or Downstroke)
  • Click Micrometer for independent conductor adjustment in increments of 0.001″ (0.025mm) and insulation adjustment in increments of 0.002″ (0.051mm)
  • Tooling lock nut allows quick change of crimp tools without disturbing other tooling
  • Fully adjustable bronze gibs with adjustable centerline location and wear compensation
  • Conversion kits available to accommodate similar terminals
  • Feed is fully adjustable from 0 to 2.00″ (0 to 50.8mm) with interchangeable latches for 0 to 1.00″ (0 to 25.4mm) or 0 to 2.00″ (0 to 50.8mm)
  • Self-containing hydraulic feeder permits the use of short press strokes to feed terminals in progressions of 0.050″ to 2.00″ (1.27 to 50.8mm)
  • The check valve regulates reel speed, which eliminates jam-ups and damage
  • The feed can be delayed until tooling has cleared the terminal strip
  • Can be designed for either Right-to-Left, Left-to-Right, or End-to-End terminals with replaceable crimping dies
  • Does not rely on press stroke, so it can be used on any press without readjustment
  • The Heavy Duty Die applies heavy gage terminals; large wire crimp from 8 thru 4/0 AWG (8mm2 to 120mm2) cable (for example, crimping battery cable terminal)
  • Feed Directions include Right-to-Left, Left-to-Right, or End-to-End. Feed is accomplished through the use of heavy-duty, large-bore air cylinders.
  • Air Assists are available for feeding terminals forward; 80 psi is required.
  • Loose Piece Shuttle Dies available
  • The Diamond Die Heavy Duty Applicator can be adapted to fit a Packard or Benchmaster seven-ton or larger press.
HYDROFEED TERMINATING APPLICATOR
HI-SPEED CRIMP APPLICATOR
HEAVY DUTY WIRE APPLICATOR

Unlock Your Manufacturing Potential With Diamond Die Tools and Crimp Applicators

Don’t let subpar tools hold you back! Choose our cutting-edge die tools and crimping applicators to unlock your manufacturing potential. Experience the elevated precision, durability, and efficiency standards that have satisfied countless industry leaders. Optimize your production process and secure your competitive edge by investing in trusted tools. Contact us today to get started!
